Speedmixer

Large SpeedMixers

This product range includes SpeedMixer™ models with mixing weight capacities of up to 20kg per run as well as volumes up to 5-gallon buckets. These SpeedMixers are specifically designed for specialty and pilot production, as well as R&D requiring large batch sizes. Due to production needs, these large SpeedMixers can be fitted with twin baskets where you can mix 2 containers simultaneously. Models in this range all have the optional capability for programmable vacuum mixing.

Scaling up for production in the larger SpeedMixers is particularly easy when they are paired with a small or medium-sized SpeedMixer.

  • Technical Specification

Technical Specification

Model Maximum
Container
Volume
Maximum
Material
[per container]
Mixing Containers [per run] Max Total Batch Size [per run] Size (HxWxD, in.) Machine Weight
(lbs)
Touch Screen Programs Mixing Zones Vacuum Mixing
DAC 10000-5000 2.5 gal (10000mL) 5kg 1 5kg 56x64x81 3700 Yes 250 up to 10 No
DAC 10000-10000 Twin 2.5 gal (10000mL) 5kg 2 10kg 56x64x81 3700 Yes 250 up to 10 No
DAC 10000-5000 VAC 2.5 gal (10000mL) 5kg 1 5kg 56x64x81 3800 Yes 250 up to 10 Yes
DAC 10000-10000 VAC Twin 2.5 gal (10000mL) 5kg 2 10kg 56x64x81 3800 Yes 250 up to 10 Yes
DAC 14000-10000 3.5 gal (14000mL) 10kg 1 10kg 56x64x81 3900 Yes 250 up to 10 No
DAC 14000-20000 Twin 3.5 gal (14000mL) 10kg 2 20kg 56x64x81 3900 Yes 250 up to 10 No
DAC 14000-10000 VAC 3.5 gal (14000mL) 10kg 1 10kg 56x64x81 4000 Yes 250 up to 10 Yes
DAC 14000-20000 VAC Twin 3.5 gal (14000mL) 10kg 2 20kg 56x64x81 4000 Yes 250 up to 10 Yes
DAC 20000-10000 5 gal (20000mL) 10kg 1 10kg 59x64x81 4150 Yes 250 up to 10 No
DAC 20000-20000 Twin 5 gal (20000mL) 10kg 2 20kg 59x64x81 4150 Yes 250 up to 10 No
